CASE CONSTRUCTION 1150M - Auxiliary Battery Connections

7-MAINTENANCE
Auxiliarybatteryconnections
DANGER
Explosionhazardand/orrunoverhazard!
Readtheprocedureintheoperator'smanualbeforejump-startorservicetoavoidinjury.
Failuretocomplywillresultindeathorseriousinjury.
D0149A
DANGER
Explosionhazard!
Whenjump-startingthemachine,connectanddisconnectthejumpercablesasinstructedinthisman-
ual.Makesurenopersonsareneartheconnectingpointsbeforestartingtheengine.Starttheengine
fromtheoperator’sseat.
Failuretocomplywillresultindeathorseriousinjury.
D0128B
Prioroperation:
Keepallunauthorizedpersonnelclearofthearea.Shiftthemachinetoneutralwiththeparkingbrakeapplied,and
theattachmentloweredtotheground.
Makesurethatthevoltageoftheboosterbatteriesis
thesameasthatofthemachinesystem(24volts).
1.Turnofftheignitionandallaccessoriesonthema-
chine(s).
2.Removethebatteryterminalcover.
3.Connectoneendofthepositive(+)cabletothepositive
(+)terminalontheboosterbattery.Connecttheother
endofthepositive(+)cabletothepositive(+)terminal
ofthedischargedbattery.
4.Connectthenegative(-)cabletothenegative(-)termi-
nalontheboosterbattery.
5.Connecttheotherendofthenegativecabletotheen-
gineblockorframeofthemachinewiththedischarged
battery.Donotconnectthenegativecabletosheet
metaloranyrotatingpart,asdamagecanresult.Do
notconnecttothenegativeterminalonthebattery.
6.Starttheengine.
7.Alwaysremovetheboosterbatterynegative(-)cable
fromthemachinerst,thenfromtheboosterbattery.
Removethepositive(+)cablefromthemachineand
thenfromtheboosterbattery.
NOTICE:Donotconnectboosterbatterycablestosheetmetaloranyrotatingpart,asdamagecanresult.
8.Installtheterminalcovers.
7-114
