CASE CONSTRUCTION 1150M - Every 1500 Hours; Drive Belt

7-MAINTENANCE
Every1500hours
Drivebelt
WARNING
Entanglementhazard!
Alwaysstoptheengineandengagetheparkingbrake,unlessotherwiseinstructedinthismanual,
beforecheckingand/oradjustinganydrivebeltorchain.
Failuretocomplycouldresultindeathorseriousinjury.
W0097A
WARNING
Movingparts!
Installallcovers,panels,andguardsafterservicingorcleaningthemachine.Neveroperatethema-
chinewithcovers,panels,orguardsremoved.
Failuretocomplycouldresultindeathorseriousinjury.
W0135A
Replacethedrivebeltwhenthehourmeterregisters1500hours.Checkthebeltvisuallyeachdayatthedailywalk
aroundforcorrecttension,wear,anddamage.Wrongbelttensionmaycausebatterychargefailure,engineover-
heating,ordrivebeltwear.
Prioroperation:
Keepallunauthorizedpersonnelclearofthearea.Parkthemachineonlevelground,inneutralwiththeparkingbrake
applied,andtheattachmentloweredtotheground,turnofftheengine,removethekey,andverifythatenginecom-
ponentshavecooledoravoidcontact.Makesurethatallresidualpressureisrelievedfromcircuitsbeforebeginning
maintenance.
Maintenancespecications
VisualcheckEvery10hoursoreveryday
ReplacebeltsEvery1500hours
NOTICE:Iftheenginerunswiththedrivebeltloose,thedrivebeltcanslipandcausetheenginetooverheatorthe
batterytoreceiveinsufcientcharge.
Replacingthedrivebelt
1.Thefanbeltislocatedinthefrontenginecompartment.
TurnthemasterdisconnectOFFbeforeremovingthe
fanbelt.
RAIL12DOZ0401AA1
