CASE CONSTRUCTION 1150M - Machine Dimensions, Weights, and Ground Pressure

8-SPECIFICATIONS
Machinespecicationsanddimensions
RAIL14DOZ0570FA1
Heightandgroundclearancedimensions
PATUNITS
ModelLTWT
LGP
A.
Topofexhauststack2796mm(110.1in)2796mm(110.1in)2796mm(110.1in)
B.Bladeheight
1119mm(44.1in)1119mm(44.1in)1119mm(44.1in)
CGroundclearanceatbellypans330.5mm(13.0in)330.5mm(13.0in)330.5mm(13.0in)
C2Groundclearanceatdrawbar448mm(17.6in)448mm(17.6in)448mm(17.6in)
C3Atcenterlineofdrawbaropening530mm(20.9in)530mm(20.9in)530mm(20.9in)
D.
Shankheight(Transportposition)343mm(13.5in)343mm(13.5in)343mm(13.5in)
E.
TopofseatheadrestCLTChainCELTChain
2414mm(95.0in)2414mm(95.0in)
F1.
Heightofcabwithairconditioning
LT,WT ,LGP
CLTChainCELTChain
2948mm(116.1in)2948mm(116.1in)
NOTE:GroundclearanceandoverallheightdimensionsarewiththegrouserfullypenetratedperISO6746-1.Add
55.5mm(2.2in)ifmachineisonsolidsurface.
**Rippertransportwithshankinmidrangeposition.
8-5
