8-SPECIFICATIONS
RAIL14DOZ0571FA2
Lengthdimensionswithbladestraight
PATTractormodels
LT
withCLTchain
WT
withCELTchain
LGPwithCELTchain
A.
Overalllengthwithoutblade,without
rearequipment
3540mm(139.4in)3540mm(139.4in)3540mm(139.4in)
B.
Overalllengthbladestraight,without
rearequipment
4844mm(190.7in)4844mm(190.7in)4844mm(190.7in)
C.Overalllength,bladestraight,with
drawbar
5088mm(200.3in)5088mm(200.3in)5088mm(200.3in)
D.
Overalllength,bladestraight,with
ripper
6150mm(242.1in)6150mm(242.1in)6150mm(242.1in)
NOTE:Overalllengthiswithbladepitchat55%.
