CASE CONSTRUCTION 1150M - Selective Catalytic Reduction (SCR) System - Replace Supply Module Filter

7-MAINTENANCE
SelectiveCatalyticReduction(SCR)system-Replacesupplymodule
lter
Cleanthein-linesupplylterwhenthemachineisnewandthehourmeterregisters100hours.Cleanevery1500
hoursthereafterormoreoftenifconditionssorequire.Thesupplylinehasasmallmeshlterwithintheline.Replace
themainlteratapproximately3000hours.
Prioroperation:
Keepallunauthorizedpersonnelclearofthearea.Parkthemachineonlevelground,inneutralwiththeparkingbrake
applied,andtheattachmentloweredtotheground,turnofftheengine,removethekey,andverifythatenginecom-
ponentshavecooledoravoidcontact.Makesurethatallresidualpressureisrelievedfromcircuitsbeforebeginning
maintenance.
1.Opentherearlefthandaccesscompartment,andlo-
catetheDEFsupplymodule.
RAPH12DOZ0121AA1
2.Removetheboltsholdingthesupplymoduleinplace,
andtiltthemoduleup.
RAIL12DOZ0189AA2
3.LocatetheDEFsupplylinelterdirectlybelowthesup-
plymodule.
4.UseasuitablecontainertocatchanyDEFuidthatis
dischargedduringlineandlterdisassembly.Cleanthe
areabeforedisassembly.
5.DisconnecttheDEFsupplylinebysqueezingthetabs
ontheconnectionandseparatethelines.
RAIL12DOZ0191AA3
7-102
