CASE CONSTRUCTION 1150M

To Next Page

To Previous Page

7-MAINTENANCE

Cabairlter

1.Locatethecabairlterbehindtheoperator’scompart-

ment.

2.Removethescrewsfromthecabairltercover,and

removethecabairltercover.

RAIL12DOZ0396AA3

3.Removetheinnercover.

4.Removetheoldlterandltermountingbracket.

5.Wipetheinsideofthecabairlterhousing.

RAIL12DOZ0187AA4

6.Replacethecabairlterwithanewone,installingthe

lterintothecabairltermountingbracket.

7.Replaceinnerairltercover,tighteningboltssecurely.

8.Replacetheoutermetalcoverandtightenscrews.

RAIL12DOZ0186AA5

7-101
