CASE CONSTRUCTION 1150M - Initial 20 Hours; Track Shoe Bolt Torque

7-MAINTENANCE
Initial20hours
Trackshoebolttorque
Checkthetorqueofthetrackshoeboltsaftertherst20hoursofoperationwithanewmachineoriftheshoeshave
beenremoved.
Prioroperation:
Keepallunauthorizedpersonnelclearofthearea.Parkthemachineonlevelground,inneutralwiththeparkingbrake
applied,andtheattachmentloweredtotheground,turnofftheengine,removethekey,andverifythatenginecom-
ponentshavecooledoravoidcontact.Makesurethatallresidualpressureisrelievedfromcircuitsbeforebeginning
maintenance.Makecertainallmatingsurfacesarecleanandfreeofdirt,rust,andpaint.
1.Tightentheboltsinthesequenceshownforthestan-
dardtrackshoe.
2.T orquethestandardlinkboltsto
380.8-435.2N·m(280.9-321.0lbft)
Torquethemasterlinkboltsto
340-380N·m(251-280lbft)
Donotovertighten.T apeachboltwithabrassorlead
hammertoensurejointisseated.Thenrechecktorque.
NOTICE:Donothitthetrackpins,bushings,linkpinboss,
orsidesofthelink.Thiscancausecomponentdamage.
RAPH12DOZ0115AA1
