7-MAINTENANCE

Worklights

Prioroperation:

Keepallunauthorizedpersonnelclearofthearea.Parkthemachineonlevelground,inneutralwiththeparkingbrake

applied,andtheattachmentloweredtotheground,turnofftheengine,removethekey,andverifythatenginecom-

ponentshavecooledoravoidcontact.Makesurethatallresidualpressureisrelievedfromcircuitsbeforebeginning

maintenance.

1.T oreplaceworklights,removethePhillipsscrewsfrom

thefrontofthelight.

RAPH12DOZ0104AA1

2.Disconnectpushonconnectors,andreplacethelamp

assembly.Pushtheconnectorson,makingcertain

connectionsarermlyinplace.

3.Replacethelampassembly,andsecuretheframewith

thePhillipsscrews.

RAIL12DOZ0196AA2
