CASE CONSTRUCTION 1150M - Ripper Shanks and Teeth

7-MAINTENANCE
Rippershanksandteeth
WARNING
Flyingobject!
Alwaysweareyeorfullfaceprotectionwhenperformingthisprocedure.
Failuretocomplycouldresultindeathorseriousinjury.
W0313A
Rippershanksorripperteethmayrequireperiodicreplacement.Usecarewhenliftingheavyobjects.Alwaysuse
adequateliftingequipment.
Prioroperation:
Keepallunauthorizedpersonnelclearofthearea.Parkthemachineonlevelground,inneutralwiththeparkingbrake
applied,andtheattachmentloweredtotheground,turnofftheengine,removethekey,andverifythatenginecom-
ponentshavecooledoravoidcontact.Makesurethatallresidualpressureisrelievedfromcircuitsbeforebeginning
maintenance.
1.Therippershankshaveathreadedoriceforlifting.
InsertanI-boltofadequatesizewhenchangingripper
shanks.
RAIL12DOZ0371AA1
2.CAUTION
Heavyobject!
Thecomponentisheavy.Usecarenottodrop
thecomponentwheninstalling,removing,or
handling.
Failuretocomplycouldresultinminorormod-
erateinjury.
C0095A
Useproperandadequateliftingequipmenttoliftthe
rippershanks.
RAIL12DOZ0370AA2
