CASE CONSTRUCTION 1150M - Hydraulic Oil

7-MAINTENANCE
Hydraulicoil
WARNING
Pressurizedhydraulicuidcanpenetratetheskinandcausesevereinjuries.
Hydraulicuidisunderextremepressure.Restthebucketorattachmentontheground.Shutthe
engineoff,turnthekeyon,andmovethehydrauliccontrolleverthroughallmovementsseveraltimes
torelieveresidualpressureinthesystem.
Failuretocomplycouldresultindeathorseriousinjury.
W0161A
Checkthelevelofthehydraulicoiltankevery10hoursoreachday.
Prioroperation:
Keepallunauthorizedpersonnelclearofthearea.Parkthemachineonlevelground,inneutralwiththeparkingbrake
applied,andtheattachmentloweredtotheground,turnofftheengine,removethekey,andverifythatenginecom-
ponentshavecooledoravoidcontact.Makesurethatallresidualpressureisrelievedfromcircuitsbeforebeginning
maintenance.
Servicespecications
TypeofoilTUTELAAUTOSUPREME™ENGINEOILSAE10W-30
Totalsystemcapacity
116.4l(30.75USgal)
Fluidlevelcheck
1.Beforeyoustarttheengine,checktheoillevelinthe
sightgauge.Iftheoiliscold,theleveliscorrectwhen
thetopoftheoilisalignedwiththeindicatormark(1).
2.Ifoilisrequired,makecertainthatallpressureisre-
lievedinthesystem.
RAPH12DOZ0053AA1
3.Slowlyloosenthetankcap(2)andtopoffuntilthe
properoillevelisreached.
RAPH12DOZ0048AA2
7-34
