CASE CONSTRUCTION 1150M - Tracks - General Specification

8-SPECIFICATIONS
Tracks-Generalspecication
TrackadjustmentHydraulic
TrackframesuspensionPivotshaftandoscillatingequalizerbeam
Heightoftrackshoegrouser52.5mm(2.07in)
Trackgauge
LT/WT/LGP1829mm(72in)
LengthoftrackongroundLT/WT/LGPwithstandardCASE
LubricatedTrack(CLT)
2590.8mm(102.0in)
LengthoftrackongroundLT/WT/LGPwithoptionalCASE
ExtendedLifeTrack(CELT)
2570.5mm(101.2in)
NumberoftrackshoepersideLT/WT/LGP
43
Numberofcarrierrollerspersideallmodels
2
NumberoftrackrollerspersideLT/WT/LGP
7
CASElubricatedtrack(CLT)Standard
CASEextendedlifetrack(CELT)Optional
NOTE:IfmachineisequippedwithoptionalCELTchaingroundpressurewillbe0.7kPa(0.1psi)greater.
LT=LongTrack
WT=WideTrack
LGP=LowGroundPressure
8-3
