8-SPECIFICATIONS
Tractormodels
LT/WT/LGP
Numberoftrackshoesperside
43
Numberofcarrierrollersperside
2
Numberoftrackrollersperside
7
Carrierrollerdiameter
140
Trackrollerraildiameter190
LengthoftrackongroundmodelwithstandardCASE
LubricatedTrack(CLT)
2590.8mm(102.0in)
LengthoftrackongroundmodelwithoptionalCASEExtended
LifeTrack(CELT)
2590.8mm(102.0in)
Trackgauge
1829mm(72in)
508mm(20in)
LT
559mm(22in)
WT
660mm(26in)WT/LGP
Trackshoewidthoptions
762mm(30in)LGP
TractorModels
***Areaoftrackonground(withCLTchain)LT/WT/LGP
508mm(20in)1bartrackshoe26323cm²(4080in²)
LT
559mm(22in)1bartrackshoe28965cm²(4490in²)LT/WT
660mm(26in)1bartrackshoe34199cm²(5301in²)
WT
762mm(30in)1bartrackshoe39484cm²(6120in²)LGP
****GroundPressure:SHOEWIDTH
20in22in26in30in
LT(72ingauge/PAT120inblade)
46.90kPa
(6.80psi)
43.90kPa
(6.37psi)
——
LT(72ingauge/PAT132inblade)
47.20kPa
(6.85psi)
44.20kPa
(6.41psi)
——
WT(80ingauge/PAT120inblade)
46.20kPa
(6.70psi)
43.60kPa
(6.32psi)
——
WT(80ingauge/PAT132inblade)
46.50kPa
(6.74psi)
43.90kPa
(6.37psi)
37.20kPa
(5.40psi)
—
LGP(80ingauge/PAT132inblade)
———
32.50kPa
(4.71psi)
*ValuesareforstandardCLT(CaseLubricatedTrack)
**ValuesareforoptionalCELT(CaseExtendedLifeTrack)
***AreaoftrackongroundvaluesforCLT—ifunitisequippedwithCELT ,areongroundis0.8%less.
****GroundpressurevaluesforCLT—ifunitisequippedwithCELT,groundpressureis0.1PSIgreater.
