3-CONTROLSANDINSTRUMENTS

Cabairlouvers

Mainairlouvers

Louversontheright-handcabsupportandleft-handcab

supportdirectairtowardthewindowsortheoperator.

Adjustmentscanbemadetodirecttheairowofthelou-

vers.

RAPH12DOZ0087AA1

Otherlouversarelocatedonthelowercontrolhousing.

RAPH12DOZ0086AA2

Recirculationairlouverandrearlouvers

Thereardeckhastwoclimatecontrollouvers(1).The

cabairlter(2)islocatedbehindtheoperator’sseatnext

totheoor.Whenthelouversareopen,airrecirculatesin

thecab.

NOTE:Alwayshavetheselouversopenformaximum

coolingwiththeairconditioningormaximumheatwiththe

heater.

RAPH12DOZ0074AA3

3-37
