CASE CONSTRUCTION 1150M - Cab Air Filter - Recirculation Filter

7-MAINTENANCE
Cabairlter-Recirculationlter
WARNING
Eyeinjuryhazard!
Wearfullcoveragesafetyglasseswithsidepanelswhenusingcompressedair.Limitairpressureto
200kPa(29psi).
Failuretocomplycouldresultindeathorseriousinjury.
W0162A
Thecabrecirculationairlterislocatedbehindtheoperator’sseat.Replacethecabairlterswhenrequired.The
cabairlterislocatedbehindtheoperatorcompartmentneartheexhaustfan.
Prioroperation:
Keepallunauthorizedpersonnelclearofthearea.Parkthemachineonlevelground,inneutralwiththeparkingbrake
applied,andtheattachmentloweredtotheground,turnofftheengine,removethekey,andverifythatenginecom-
ponentshavecooledoravoidcontact.Makesurethatallresidualpressureisrelievedfromcircuitsbeforebeginning
maintenance.
Recirculationlter
1.Removetheretainingscrewthatholdstherecirculation
ltercoverinplace,andremovetherecirculationlter.
2.Wipethehousingclean.
RAPH12DOZ0074AA1
3.Replacetherecirculationlterwithanewone.
4.Reinstallthenewrecirculationlter,andsecuretheac-
cessltercover.
RAIL12DOZ0164AA2
7-100
