Turning
Turnsareperformedinconjunctionwithforwardorre-
versemotionofthecrawler.
Steeringagradualturn
1.Movethedirectioncontrolleverforwardandtothe
lefttotheeleveno’clockposition.Thecrawlerwill
graduallyturntotheleft.
2.Movethedirectioncontrolleverforwardandtothe
righttotheoneo’clockposition.Thecrawlerwillgrad-
uallyturntotheright.
RCIL10CWL016AAL4
Powerturn
1.Movethedirectioncontrollevertowardtheteno’clock
position,andthecrawlerwillturnsharpertotheleft
withappropriatepowertoeachtrack.
2.Movethedirectioncontrollevertowardthetwoo’clock
position,andthecrawlerwillturnsharpertotheright
withappropriatepowertoeachtrack.
Counterrotation
1.Leftcounterrotation
Counterrotationcanbeaccomplishedfromamoving
orstoppedposition.Movethedirectioncontrollever
forwardandthenstraightlefttothenineo’clockposi-
tion(pastthefeelpoint).
2.Rightcounterrotation
Movethedirectioncontrolleverforwardandthen
straightrighttothethreeo’clockposition(pastthefeel
point).
NOTE:Practicecounterrotationatareducedspeed
inaclear,openarea.
