7-MAINTENANCE

4.Enginehood-frontleft-handsideofthemachine.

Engineaircleaner(1)

Oildipstick(2)

Oilll(3)

RAIL12DOZ0401AA4

5.Rearaccesspanel

Hydraulicoildrain

RAPH12DOZ0099AA5

6.Undercarriagepanels

Coolantdrain

Oildrain

RAPH12DOZ0095AA6

7.Hoodtoppanel

Coolantcheckandll

RAPH12DOZ0072AA7

7-30
