7-MAINTENANCE

5.Removetheengineoildrainplug(2).

RAPH12DOZ0096AA3

6.Locatetheoillter(3)intherightfrontenginecompart-

ment.Cleantheareaaroundthelterofdirtanddebris.

RAIL12DOZ0192AA4

Replaceoillter

7.Turntheoillter(3)housingcounterclockwisetore-

move.Removeanddiscardthelterfollowinglocalen-

vironmentalandwasteregulations.

8.Applyathinlayerofcleanoiltothenewltergasket.

9.Turnthenewoillterontothebaseuntilthegasket

makescontactwiththebase,andthenturnbyhandan

additional3/4turn.Neverusealterwrenchtoinstall

anewlter.

RAIL12DOZ0192AA5

10.Closetheoildrain.

7-57
