7-MAINTENANCE

Removingairfromthefuelsystem

1.Removeairfromthefuelsystemafterchangingthefuel

lter.Removingairfromthefuelsystemmayalsobe

necessaryifthemachinerunsoutoffuel,ifthefuel

systemhasbeenserviced,orifthemachinehasbeen

instorage.

2.MakecertainthatthefueltankshutoffisintheONpo-

sition.

3.Loosentheairbleedscrewoneortwoturns.

4.Operatethehandprimeruntilnoairbubblesowfrom

aroundtheairbleedscrew.

5.Tightentheairbleedscrew.

6.Starttheengine,andcheckforleaks.

RAPH12DOZ0056AA3

7-60
