7-MAINTENANCE

7.Replacethefanguardandboltinplace.

RAIL12DOZ0402AA5

Belttension

Thecorrecttensionforanewdrivebeltis:

623-712N·m(459.5-525.1lbft).

Tensionforauseddrivebeltis:

400-534N·m(295.0-393.9lbft)tension.

7-77
