7-MAINTENANCE

7.Installthenewsecondaryairlter.DONOTcleanthe

secondaryairlter.Youmustreplacethesecondaryair

lter.

8.Installthenewprimaryairlter,makingcertainitseats

properly.

RAIL12DOZ0169AA6

9.Installtheairltercover,fasteningthelocksinplace.

10.Pushontheendofdustvalvetodraindustanddebris

fromtheairlterhousing.

11.Closeandlocktheaccessdoor.

RAIL12DOZ0172AA7

7-92
