3-CONTROLSANDINSTRUMENTS
Slideadjustmentlever
Pulltheslideadjustmentleverupandadjusttheseatfor-
wardorbackwardasrequired.Releasethelevertolock
theseatinposition.Alwaysmakeadjustmentsfromthe
frontcenteroftheadjustmentbar.
RAPH12DOZ0075AA3
Seatheightadjustment
Toraisetheseat,pushtheknobandremoveyourweight
offtheseat.Allowtheairtobuildtothedesiredheight.
Releasetheknobatthedesiredheight.
Tolowertheseat,pulltheknobouttoreleaseair.Release
theknobatthedesiredheight.
NOTE:Overtime,therewillbesomeairloss.Readjust
theseatatthebeginningofeachworkday.
RAIL12DOZ0651AA4
Comfortcontrol-mechanical
suspensionseat
Sitintheseat,andusethecontrolknobtoadjusttheseat
foryourdesiredride.
RAPH13DOZ1162AA5
3-5
