3-CONTROLSANDINSTRUMENTS
5.DieselExhaustFluid(DEF)levelgauge
Themonitorscreenislocatedinthe
centeroftheconsole.TheDEFlevelbar
gaugeindicatesthelevelofdieselexhaust
uidintheDEFtank.Whenallbarsare
illuminated,thetankisfull.Illuminatedbars
indicatethelevelofuidremaininginthe
DEFtank.Whenthetankisat5–10%of
tankvolume,thewarningsystemwillash
and/orwillashandsoundanaudiblealarm
dependentuponDEFlevels.
NOTICE:IftheDEFsystembecomescompletelyempty,
theenginewilllosesignicantpower.
RAIL12DOZ0224AA8
DEFlevelgauge
GaugeindicationCondition
Masterindicator
Gaugestatus
Alarmstatus
6–10%
Noenginepowerloss
Caution(yellow)
FlashesNone
5%andbelow
Moderateengine
powerloss
Caution(yellow)Flashesfor4
seconds,thensteady
Continuous
Empty
Severeenginepower
loss
Stop(red)
Flashescontinuously
Continuous
3-21
