3-CONTROLSANDINSTRUMENTS

Enginehandthrottle

Theenginehandthrottlecontrolsenginespeed.Speeds

aredesignatedfast(haresymbol)andslow(tortoisesym-

bol).Seetheadjacentinformationalsign.Chooseengine

speedsuitabletooperateandcompletethejobefciently.

Donotshuttheenginedownfromfullthrottle.

•

Pulltheenginehandthrottlelever(2)BACKtoincrease

theenginespeed.

•

PushthethrottleleverFORWARDtodecreasetheen-

ginespeed.Seetheinstructionaldecallocatedtothe

rightofthethrottle.

RAPH12DOZ0080AA6

874221887

3-31
