2-SAFETYINFORMATION

LEIL13WHL0302AA31

Location:left-handandright-handsideofthemachine,

nearthefanguard.

WARNING

Entanglementhazard!

Keepclearorstoptheenginebeforeservicing.

Failuretocomplywiththiswarningcouldresultindeath

orseriousinjury.

NorthAmericandecalnumber:87488606

FrenchCanadiandecalnumber:87488607

Spanishdecalnumber:87488608

87488606_B32

LEIL13WHL0302AA33

Location:left-handandright-handsideofthemachine,

nearthefanguard.

WARNING

Explosionhazard!

Donotuseether.

Failuretocomplywiththiswarningcouldresultindeath

orseriousinjury.

NorthAmericandecalnumber:47728994

FrenchCanadiandecalnumber:47728074

Spanishdecalnumber:8603094

8603092_34

2-31
