27-23
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 27 Configuring Network Object NAT
Configuration Examples for Network Object NAT
Figure 27-38 Defining the NAT Pool Addresses
c.
Choose the new network object by double-clicking it. Click OK to return to the NAT configuration.
Figure 27-39 Choosing the New Network Object
Step 5 Configure the real and mapped interfaces by clicking Advanced:
Figure 27-40 Configuring Interfaces
Step 6
Click OK to return to the Edit Network Object dialog box, click then click OK again to return to the
NAT Rules table.
Step 7 Create a network object for the outside web server:
