28-24
Cisco ASA 5500 Series Configuration Guide using ASDM
OL-20339-01
Chapter 28 Configuring Twice NAT
Configuration Examples for Twice NAT
Figure 28-44 Adding a NAT Rule
By default, the NAT rule is added to the end of section 1. If you want to add a NAT rule to section 3,
after the network object NAT rules, choose Add NAT Rule After Network Object NAT Rules.
The Add NAT Rule dialog box appears.
Figure 28-45 Add NAT Rule Dialog Box
Step 10
Set the source and destination interfaces:
Figure 28-46 Setting the Interfaces
Step 11 For the Original Source Address, type the name of the inside network object (myInsideNetwork) or click
the browse button to choose it.
Step 12 For the Original Destination Address, click the browse button to add a new network object for DMZ
network 2 in the Browse Original Destination Address dialog box.
a. Add the new network object.
