Chapter 8 Configuring SNMP
SNMP Overview
8-20
Cisco 4700 Series Application Control Engine Appliance Administration Guide
OL-11157-01
Table 8-2 identifies the supported SNMP notifications (traps) for the ACE.
Note The clogOrigin ID and clogOriginIDType variable bindings are appended to each
notification listed in Table 8-2 to identify from which c
hassis, slot, and context
combination that the event trap has originated.
TCP-MIB CISCO-TCP-STD-
CAPABILITY
Defines managed objects for managing the
imp
lementation of the Transmission Control
Protocol (TCP).
The TCP MIB is described in RFC 4022.
UDP-MIB CISCO-UDP-STD-
CAPABILITY
Defines managed objects for managing
imp
lementation of the User Datagram
Protocol (UDP).
The UDP MIB is described in RFC 4113.
Table 8-1 SNMP MIB Support (continued)
MIB Support Capability MIB Description
Ta b l e 8-2 SNMP Trap Support
Notification Name
Location of the
Notification Description
authenticationFailure SNMPv2-MIB SNMP request fails because the NMS did
not authe
nticate with the correct
community string.
cesRealServerStateUp CISCO-ENHANCED-
SLB-MIB
State of a real server configured in a server
f
arm is up due to user intervention.
cesRealServerStateDown CISCO-ENHANCED-
SLB-MIB
State of a real server configured in a server
f
arm is down due to user intervention.
cesRealServerStateChange CISCO-ENHANCED-
SLB-MIB
State of a real server configured in a server
f
arm changed to a new state as a result of
something other than a user intervention.
This notification is sent for situations such
as ARP failures, probe failures, and so on.
