1-25
Cisco 4700 Series Application Control Engine Appliance Administration Guide
OL-11157-01
Chapter 1 Setting Up the ACE
Synchronizing the ACE with an NTP Server
For example, to display a summary of all peers, enter:
switch/Admin# show ntp peers
Table 1-3 describes the fields in the show ntp peers command output.
Ta b l e 1-3 Field Descriptions for the show ntp peers Command
Field Description
Peer IP Address The IP address of each associated peer
Serv/Peer Indicates whether the peer functions as an NTP server
or NTP peer
For example, to display the NTP input/output statistics, enter:
switch/Admin# show ntp statistics io
Table 1-4 describes the fields in the show ntp statistics io command output.
Peer IP Address IP address of each associated
peer
Serv/Peer Indication of whether the peer functions
as an NTP
server or NTP peer
Table 1-2 Field Descriptions for the show ntp peer-status Command
Field Description
Ta b l e 1-4 Field Descriptions for show ntp statistics io Command
Field Description
Time since reset Time since the last reset of the NTP software on the
pr
imary server
Receive buffers Total number of UDP client-receive buffers
Free receive buffers Current number of available client-receive buffers
Used receive buffers Current number of unavailable client-recei
ve buffers
Low water refills Total number of times buffers were added, which also
indicates
the number of times there have been low
memory resources during buffer creation
