Cisco IE-5000 User Manual

245
Configuring Web-Based Authentication
Information About Configuring Web-Based Authentication
Figure 26 Customized Web Banner
If you do not enable a banner, only the username and password dialog boxes appear in the web authentication login
screen, and no banner appears when you log into the switch, as shown in Figure 27.
Figure 27 Login Screen with No Banner
For more information, see the Cisco IOS Security Command Reference and Configuring a Web Authentication Local
Banner, page 252.

Cisco IE-5000 Specifications

General

Model	IE-5000
Category	Industrial Ethernet Switch
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
MAC Address Table Size	16, 000 entries
Ports	16 or 24 10/100/1000 ports
Uplink Ports	4 SFP ports
Operating Temperature	-40°C to 70°C
Power Supply	Dual redundant power supplies
Mounting	DIN rail
Management	Web GUI, CLI, SNMP
Input Voltage	24 VDC or 110/220 VAC
Layer	Layer 2/3
Jumbo Frame Support	Up to 9216 bytes
