Cisco IE-5000 User Manual

536
Configuring SNMP
How to Configure SNMP
Command Purpose
1. configure terminal Enters global configuration mode.
2. snmp-server engineID {local engineid-string
| remote ip-address [udp-port port-number]
engineid-string}
Configures a name for either the local or remote copy of SNMP.
 The engineid-string is a 24-character ID string with the name
of the copy of SNMP. You need not specify the entire
24-character engine ID if it has trailing zeros. Specify only the
portion of the engine ID up to the point where only zeros
remain in the value. For example, to configure an engine ID of
123400000000000000000000, you can enter this:
snmp-server engineID local 1234
 If you select remote, specify the ip-address of the device that
contains the remote copy of SNMP and the optional User
Datagram Protocol (UDP) port on the remote device. The
default is 162.

Cisco IE-5000 Specifications

General

Model	IE-5000
Category	Industrial Ethernet Switch
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
MAC Address Table Size	16, 000 entries
Ports	16 or 24 10/100/1000 ports
Uplink Ports	4 SFP ports
Operating Temperature	-40°C to 70°C
Power Supply	Dual redundant power supplies
Mounting	DIN rail
Management	Web GUI, CLI, SNMP
Input Voltage	24 VDC or 110/220 VAC
Layer	Layer 2/3
Jumbo Frame Support	Up to 9216 bytes
