Configuring Cisco IOS IP SLAs Operations
Configuration Examples for Configuring Cisco IP SLAs Operations
Configuration Examples for Configuring Cisco IP SLAs
Operations
Configuring an ICMP Echo IP SLAs Operation: Example
This example shows how to configure an ICMP echo IP SLAs operation:
Switch(config)# ip sla 12
Switch(config-ip-sla)# icmp-echo 172.29.139.134
Switch(config-ip-sla-echo)# frequency 30
Switch(config-ip-sla-echo)# exit
Switch(config)# ip sla schedule 5 start-time now life forever
Switch(config)# end
Switch# show ip sla configuration 22
IP SLAs, Infrastructure Engine-II.
Entry number: 12
Owner:
Tag:
Type of operation to perform: echo
Target address: 2.2.2.2
Source address: 0.0.0.0
Request size (ARR data portion): 28
Operation timeout (milliseconds): 5000
Type Of Service parameters: 0x0
Verify data: No
Vrf Name:
Schedule:
Operation frequency (seconds): 60
Next Scheduled Start Time: Pending trigger
Group Scheduled : FALSE
Randomly Scheduled : FALSE
Life (seconds): 3600
Entry Ageout (seconds): never
Recurring (Starting Everyday): FALSE
Status of entry (SNMP RowStatus): notInService
Threshold (milliseconds): 5000
Distribution Statistics:
Number of statistic hours kept: 2
Number of statistic distribution buckets kept: 1
Statistic distribution interval (milliseconds): 20
History Statistics:
show ip sla mpls-lsp-monitor
{collection-statistics | configuration | ldp
operational-state | scan-queue | summary
[entry-number] | neighbors}
Displays MPLS label switched path (LSP) Health Monitor operations.
show ip sla reaction-configuration
[entry-number]
Displays the configured proactive threshold monitoring settings for all IP
SLAs operations or a specific operation.
show ip sla reaction-trigger [entry-number] Displays the reaction trigger information for all IP SLAs operations or a
specific operation.
show ip sla responder Displays information about the IP SLAs responder.
show ip sla standards Displays information about the IP SLAs standards.
show ip sla statistics [entry-number |
aggregated | details]
Displays current or aggregated operational status and statistics.
Command Purpose
