Cisco ONS 15454 - TL1 Craft Interface Installation

Before you can connect an ONS 15454 ANSI to other ONS 15454 ANSI shelves or to a LAN, you must
change the default IP address that is shipped with each ONS 15454 ANSI (192.1.0.2).
Table 13: LAN Pin Assignments
RJ-45 PinsBackplane PinsPin Field
1B2LAN 1 Connecting to data circuit-terminating equipment (DCE
1
, a hub or
switch)
2A2
3B1
6A1
1
B1LAN 1Connecting to data terminal equipment (DTE) (a PC/workstation or
router)
2A1
3B2
6A2
1
The Cisco ONS 15454 ANSI is DCE.
TL1 Craft Interface Installation
You can use the craft pins on the ONS 15454 ANSI backplane or the EIA/TIA-232 port on the
TCC2/TCC2P/TCC3 faceplate to create a VT100 emulation window to serve as a TL1 craft interface to the
ONS 15454 ANSI. Use a straight-through cable to connect to the EIA/TIA-232 port. The following table
shows the pin assignments for the CRAFT pin field.
You cannot use the craft backplane pins and the EIA/TIA-232 port on the TCC2/TCC2P/TCC3 card
simultaneously.
Note
To use the serial port craft interface wire-wrap pins on the backplane, the DTR signal line on the backplane
port wire-wrap pin must be connected and active.
Note
Table 14: Craft Interface Pin Assignments
FunctionContactPin Field
ReceiveA1Craft
TransmitA2
GroundA3
DTRA4
