Cisco ONS 15454 - DLP-G677 Inspect the ONS 15454, ONS 15454 M2, and ONS 15454 M6 Shelves

NoneTools/Equipment
NonePrerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Procedure
Step 1 When you receive the ONS 15454, ONS 15454 M2, or ONS 15454 M6 system equipment at the installation
site, open the top of the box. The Cisco Systems logo designates the top of the box.
Step 2 Remove the foam inserts from the box. The box contains the ONS 15454 shelf (wrapped in plastic) and a
smaller box of items needed for installation.
Step 3 To remove the shelf, grasp both rings of the shelf removal strap and slowly lift the shelf out of the box.
Step 4 Open the smaller box of installation materials, and verify that you have all items listed in the Required Tools
and Equipment, on page 9.
If the shelf and ancillary units are ordered separately, then the power modules, LCD module, ECU
or ECU2 module, fan-tray assembly, and mounting brackets are shipped separately.
Note
Step 5 Return to your originating procedure (NTP).
DLP-G677 Inspect the ONS 15454, ONS 15454 M2, and ONS 15454 M6 Shelves
This task verifies that all parts of the shelf are in good condition.Purpose
Pinned hex (Allen) key for front doorTools/Equipment
DLP-G676 Unpack and Verify the ONS 15454, ONS 15454 M2, and ONS 15454
M6 Shelves , on page 20
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Procedure
Step 1 Open the shelf using the pinned hex key. For more information, see the DLP-G9 Open the Front Cabinet
Compartment (Door) , on page 57.
Step 2 Verify the following:
• The pins are not bent or broken.
