Cisco ONS 15454 - DLP-G587 Mounting the Bracket with Air Deflectors (Front-To-Back) on the ONS 15454 M2; Shelf for ETSI Rack Configuration

Figure 126: Mounting the Air Deflectors (Front-to-Front) on the ONS 15454 M2 Shelf for ETSI Rack Configuration
Step 16 Return to your originating procedure (NTP).
DLP-G587 Mounting the Bracket with Air Deflectors (Front-to-Back) on the ONS 15454 M2 Shelf
for ETSI Rack Configuration
This task installs the bracket with air deflectors (front-to-back) on the ONS 15454
M2 shelf for ETSI rack configuration.
Purpose
• #2 Phillips Dynamometric screwdriver
• Medium slot-head screwdriver
• Small slot-head screwdriver
Tools/Equipment
NTP-G305 Unpack and Inspect the ONS 15454, ONS 15454 M2, and ONS 15454
M6 Shelves, on page 20
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Use only the fastening hardware provided with the ONS 15454 M2 to prevent loosening, deterioration, and
electromechanical corrosion of the hardware and joined material.
Caution
The air deflectors can be installed only in the front position of the chassis.
Note
Cisco ONS 15454 Hardware Installation Guide
205
Installing the ONS 15454 M2 Shelf
DLP-G587 Mounting the Bracket with Air Deflectors (Front-to-Back) on the ONS 15454 M2 Shelf for ETSI Rack Configuration
