Cisco ONS 15454 - DLP-G30 Install the Flexlayer Shelf

Procedure
Step 1 The Y-cable module tray requires 1 RU in a standard 19-inch (482.6-mm) or 23-inch (584.2-mm) rack. Locate
the RMU space specified in your site plan. Use the Cisco TransportPlanner Internal Connections Report to
determine how many Y-cable modules you need to install.
Step 2 Verify that the mounting brackets attached to the unit are correct for your rack size. Complete DLP-G3 Reverse
the Mounting Bracket to Fit a 19-inch (482.6-mm) Rack (ANSI Only), on page 33 as required.
Step 3 Align the chassis with the rack mounting screw holes, insert the four screws, and tighten.
Step 4 Return to your originating procedure (NTP).
DLP-G30 Install the FlexLayer Shelf
This task installs the FlexLayer shelf. Perform this task if you are installing any
FlexLayer modules.
Purpose
#2 Phillips Dynamometric screwdriver
FlexLayer shelf (15216-FL-SA)
#14 AWG wire (minimum) for frame grounding
Tools/Equipment
NonePrerequisite
Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Procedure
Step 1 The FlexLayer shelf requires 1 RU in a standard 19-inch (482.6-mm) or 23-inch (584.2-mm) rack. Locate the
RMU space specified in your site plan.
Step 2 A set of mounting brackets are included with the FlexLayer mounting kit, one set each for 19-inch (482.6-mm)
or 23-inch (584.2-mm) racks. Verify that your chassis is equipped with the correct set of brackets for your
rack. Change the brackets as required.
Step 3 Align the chassis with the rack mounting screw holes; one at a time, insert and tighten the three screws.
Step 4 Connect a frame ground to the ground terminal provided on either side of the chassis. Use minimum #14
AWG wire.
Step 5 Repeat this task as necessary for each FlexLayer shelf you want to install.
Step 6 Return to your originating procedure (NTP).
Cisco ONS 15454 Hardware Installation Guide
127
Installing the ONS 15454 M12 (ANSI and ETSI) Shelf
DLP-G30 Install the FlexLayer Shelf
