Step 5 Return to your originating procedure (NTP).
DLP-G294 Install LAN Wires in ONS 15454 M2
This task installs the LAN wires in ONS 15454 M2.Purpose
Standard CAT-5 Ethernet cable straight-through for data terminal equipment
(DTE) or crossover for data circuit-terminating equipment (DCE) or RJ-45
connector
Crimping tool for RJ-45 connector
0.51 mm² or 0.64 mm² (#22 or #24 AWG) wire, preferably standard CAT-5
Tools/Equipment
NTP-G267 Install the Power Module in the ONS 15454 M2 Shelf, on page 230Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Procedure
Step 1 Using a 0.51 mm² or 0.64 mm² (#22 or #24 AWG) wire or a standard CAT-5 Ethernet cable, connect the wires
to the RJ-45 connector.
Step 2 Return to your originating procedure (NTP).
NTP-G313 Install and Configure the TNC, TNCE, TSC, or TSCE Card
This procedure describes how to install and configure the TNC, TNCE, TSC, or
TSCE card.
Purpose
Redundant TNC/TNCE/TSC/TSCE cards on Cisco ONS 15454 M6 shelf (required)
Stand-alone TNC/TNCE/TSC/TSCE card on Cisco ONS 15454 M2 shelf (required)
Tools/Equipment
NTP-G271 Install the Power and Ground to the ONS 15454 M2 Shelf, on page
239
NTP-G14 Install DWDM Equipment, page 1-66
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
Provisioning or higherSecurity Level
