FunctionSignal NameDB-62 Pin Connector
Extra alarm 10EXALM10+34
Extra alarm 11EXALM11–35
Extra alarm 11EXALM11+36
Normally open output pair number 1ALMOUP0–37
Normally open output pair number 1ALMOUP0+38
GroundFGND39
Normally open output pair number 2ALMOUP1–40
Normally open output pair number 2ALMOUP1+41
Normally open output pair number 3ALMOUP2–42
Normally open output pair number 3ALMOUP2+43
Normally open output pair number 4ALMOUP3–44
Normally open output pair number 4ALMOUP3+45
Normally open minor audible alarmAUDALM0–46
Normally open minor audible alarmAUDALM0+47
Normally open major audible alarmAUDALM1–48
Normally open major audible alarmAUDALM1+49
Normally open critical audible alarmAUDALM2–50
Normally open critical audible alarmAUDALM2+51
GroundFGND52
Normally open remote audible alarmAUDALM3–53
Normally open remote audible alarmAUDALM3+54
Normally open minor visible alarmVISALM0–55
Normally open minor visible alarmVISALM0+56
Normally open major visible alarmVISALM1–57
Normally open major visible alarmVISALM1+58
Normally open minor visible alarmVISALM2–59
Normally open minor visible alarmVISALM2+60
Normally open minor visible alarmVISALM3–61
Cisco ONS 15454 Hardware Installation Guide
103
Installing the ONS 15454 M12 (ANSI and ETSI) Shelf
DLP-G20 Install Alarm Wires on the MIC-A/P (ETSI Only)
