NTP-G310 Upgrade the ONS 15454 Multishelf Configuration
Using the ONS 15454 M6
Use this procedure to upgrade the existing ONS 15454 multishelf configuration
using the ONS 15454 M6 as subtending shelves and configure the Catalyst
switches using the IOS commands.
Purpose
• If there are no free ports in the Cisco Catalysts 2950, two Cisco Catalyst
3560 switches must be installed in same rack as the node controller shelf;
see the Cisco Catalyst 3560 product documentation for installation
instructions.
• Cross-over (CAT-5) LAN cables
Tools/Equipment
• NTP-G15 Install the Common Control Cards, on page 131
• NTP-G313 Install and Configure the TNC, TNCE, TSC, or TSCE Card, on
page 261
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
The multishelf management (MSM) ports are present on the ECU module. The MSM ports located on the left
side of the ECU module correspond to the TNC/TNCE/TSC/TSCE card in Slot 1, and the MSM ports located
on the right side correspond to the TNC/TNCE/TSC/TSCE card in Slot 8. For more information about the
ECU module and MSM ports, see the External Connection Units, on page 342.
Note
Procedure
Step 1 Complete the necessary task as applicable:
• To upgrade the existing ONS 15454 multishelf configuration that has the Cisco Catalyst 2950 switches,
complete the DLP-G687 Upgrade the ONS 15454 Multishelf with the Catalyst 2950 Switch Configuration,
on page 420.
• To upgrade the existing ONS 15454 multishelf configuration that has the MS-ISC card, complete the
DLP-G688 Upgrade the ONS 15454 Multishelf with MS-ISC Card Configuration, on page 423.
Step 2 To configure the Catalyst 2950 switch using IOS commands, complete the NTP-G298 Configure a Cisco
Catalyst 2950 or Catalyst 3560 (Active and Standby) for a ONS 15454 Multishelf Node, on page 152 .
Step 3 To configure the Catalyst 3560 switch using IOS commands, complete the NTP-G298 Configure a Cisco
Catalyst 2950 or Catalyst 3560 (Active and Standby) for a ONS 15454 Multishelf Node, on page 152 .
Cisco ONS 15454 Hardware Installation Guide
419
Installing the ONS 15454 M6 Shelf
NTP-G310 Upgrade the ONS 15454 Multishelf Configuration Using the ONS 15454 M6
