Table 47: ONS 15454 M6 DC Power Specifications
Maximum
Load
Input Voltage RangeCurrentNominal
Voltage
RatingDC Power
Module
1440 W–40.5 to –57.6 VDC30
Amp
–48 VDC30
Amp
15454-M6-DC
–50 to –72 VDC24
Amp
–60 VDC
960 W–40.5 to –57.6 VDC20
Amp
–48 VDC20
Amp
15454-M6-DC20
–50 to –72 VDC16
Amp
–60 VDC
1920 W–40.5 to –57.6 VDC40
Amp
-48 VDC40
Amp
15454-M6-DC40
–50 to –72 VDC32
Amp
-60 VDC
When the ONS 15454 M6 shelf is powered at –60 VDC (nominal), only these cards can be installed: TNC,
OPT-AMP-C, OPT-AMP-17-C, OPT-EDFA-17, OPT-EDFA-24, 17 SMR9 FS, 24 SMR9 FS, 34 SMR9 FS,
SMR20 FS, SMR20 FS CV, 12-AD-FS, 16-AD-FS, 100GS-CK-LC, MR-MXP cards, and the
15454-M6-ECU-60 card.
Note
• 15454-M6-DC, 15454-M6-DC20, and 15454-M6-DC40 shelf power consumption (configuration
dependent):
• 130 W with 15454-M6-FTA Fan Tray, LCD, and ECU module
• 140 W with 15454-M6-FTA2 Fan Tray, LCD, and ECU module
• When you use the 60V DC power module for ONS 15454 M6, you must go to CTC (shelf-view)
Provisioning > General > Power Monitor and set the following threshold values:
• ELWBATVG (Extreme Low Battery Voltage)=-50 Vdc
• LWBATVG (Low Battery Voltage)=-50 Vdc
• HIBATVG (High Battery Voltage)=-72 Vdc
• EHIBATVG (Extreme High Battery Voltage)=-72 Vdc
• Power terminals—DSUB 3 poles for ETSI applications and terminal block, double pole for ANSI
applications.
• External fuse must not exceed 40 A
