Configuring SIP, SPCP, and NAT
Configuring SIP
Cisco SPA and Wireless IP Phone Administration Guide 105
5
STEP 6 Click Submit All Changes.
Configuring a SIP Proxy Server
To configure SIP proxy and registration parameters:
STEP 1 Log in to the web administration interface.
STEP 2 Click Admin Login and advanced.
STEP 3 Click the Extension <number> tab.
STEP 4 Configure the proxy and registration parameters for each extension.
Auth INVITE When enabled, authorization is required for initial
incoming INVITE requests from the SIP proxy.
NOTE: Not applicable to the WIP310.
Ntfy Refer On 1xx-
To - I n v
If set to yes, as a transferee, the phone will send a NOTIFY with
Event:Refer to the transferor for any 1xx response returned by
the transfer target, on the transfer call leg.
If set to no, the phone will only send a NOTIFY for final
responses (200 and higher).
NOTE: Not applicable to the WIP310.
Use Anonymous
with RPID
This parameter applies only if <SIP Remote-Party-ID> is set to
yes; otherwise, it is ignored.
If the parameter is set to yes, the FROM header's display-name
and user-id fields are set to anonymous when the caller blocks
his caller-id. If the parameter is set to no, the FROM header's
display-name and user-id are not masked. The Remote-Party-
ID header indicates privacy=full when the caller wishes to
block his caller-id.
Default: yes.
NOTE: Not applicable to the WIP310.
Set G729 annexb
Configure G.729 Annex B settings.
NOTE Not applicable to the SPA525G.
Parameter Description
