Upgrading The Computer
6 - 12 Upgrading the System Memory (RAM)
6
Upgrading the System Memory (RAM)
The computer has four memory sockets for 204 pin Small Outline Dual In-line (SO-
DIMM) DDR III (DDR3) type memory modules (see “Memory” on page E - 2).
The total memory size is automatically detected by the POST routine once you turn
on your computer.
Removing the Primary System Memory (3 memory sockets)
1. Turn off the computer, and turn it over and remove the battery.
2. Remove screws - from the bottom of the computer.
Figure 6 - 8
Bottom Cover
Screws
To Next Page
