System Map: Bottom View
Figure 1 - 9
Bottom View
1. Fan Outlet/Intake
2. Component Bay
Cover
3. Battery (HDD Bay
located under the
battery)
4. HDD Bay

Overheating
To prevent your comput-
er from overheating make
sure nothing blocks the
vent(s)/fan intake(s)
while the computer is in
use.
1
3
4

Battery Information
Always completely discharge, then fully charge, a new battery before using it. Completely
discharge and charge the battery at least once every 30 days or after about 20 partial dis-
charges. See “Battery Information” on page 3 - 11 for full instructions.
