Clevo P570WM

Upgrading The Computer
6 - 14 Upgrading the System Memory (RAM)
6
5. Remove screws - from the keyboard.
6. Carefully lift the keyboard up, being careful not to bend the keyboard ribbon cable
or keyboard LED cable.
7. Disconnect the keyboard ribbon cable from the locking collar socket, and the
keyboard LED cable from its locking collar socket.
Figure 6 - 11
Keyboard Screw
Removal
Figure 6 - 12
Disconnect the
Keyboard Cables
7
11
87 9 10 11
12
13
12
13
