Clevo P570WM

Upgrading The Computer
6 - 16 Upgrading the System Memory (RAM)
6
10. Remove the keyboard shielding plate .
11. Gently pull the two release latches ( &
) on the sides of the memory socket in
the direction indicated below.
Figure 6 - 15
Keyboard Shielding
Plate Removal

Contact Warning
Be careful not to touch
the metal pins on the
module’s connecting
edge. Even the cleanest
hands have oils which
can attract particles, and
degrade the module’s
performance.
Figure 6 - 16
RAM Module
Release
19
19
20
21
20
21
20
21
20
21
