Clevo P570WM

Upgrading The Computer
Upgrading the System Memory (RAM) 6 - 23
6
11. Replace the fan unit above the RAM module slot and replace screws - , then
reconnect the cable .
12. Carefully Insert the heatsink .
Figure 6 - 26
Fan Unit Screws &
Cable
Figure 6 - 27
Heatsink Insertion
26
29
30
26
29
28
30
27
31
31
