Clevo P570WM

Upgrading The Computer
6 - 30 Upgrading the Video Card
6
Dual Video Cards
If your system includes two video cards you will need to disconnect the cable be-
tween the master and slave cards (do not forget to reconnect the cable if you are re-
placing two cards).

Dual Video Card
Connection
The cable between the
master and slave video
cards connect to the
connectors marked at
point. , and the cable
should run behind the
video card on the
right.
Figure 6 - 34
Dual Video Cards
26
25
25
26 26
