Clevo P570WM

Upgrading The Computer
6 - 34 Upgrading the Video Card
6
8. Hold the heatsink by the tab & and insert it back on the card as pictured.
9. Secure the screws - in the order indicated on the heat sink unit label
(and heat sink itself).

Heat Sink Screws
Make sure you remove
the heat sink screws in
the order -
(screw
first to screw
last). This order is in-
dicated on the label (and
on the heat sink itself).
Figure 6 - 38
Video Card Heat
Sink Screw Removal
31
36
31
36
29
30
31
36
40
40
29
30
31
32
33
34
35
36
