INSTALLING THE TRANSCEIVER
OVERVIEW OF FIXED STATIONS
ENVOY™ TRANSCEIVER GETTING STARTED GUIDE 163
Figure 47: Typical fixed station
NOTE: A range of ancillary equipment may be connected to the
Envoy Transceiver using the 6-way and 15-way
connectors at the rear of the RFU.
RF Unit
™
Type 2210
Serial No.
antenna control
antenna
battery
RFU
10-way
connector
15-way
connector
6-way
connector
power supply
AC mains
tuner
(optional)
broadband
antenna
Desk Console
™
desk console
08-07205-00x
08-03255
08-01503-00x
08-05627-00x
3020 Transceiver Supply
