INSTALLING THE TRANSCEIVER
OVERVIEW OF MOBILE STATIONS
ENVOY™ TRANSCEIVER GETTING STARTED GUIDE 159
1 Place the RFU into the cradle and push it under the tabs at the
rear of the cradle, then hold the clamp against the front of the
RFU.
1 Rotate the key clockwise, then push the key toward the base of
the cradle to lock the RFU into position.
Connecting a mobile Envoy™ station
NOTE: A typical mobile station is shown in Figure 46.
To connect a mobile station:
1 Connect the cable (Codan part number 08-06022-001) from the
handset and speaker connector to the 10-way plug on the cable
lead from the RFU, then secure the locking ring tightly into
position.
1 Connect the plug of the handset cable to the socket on the
handset and speaker connector, then secure the locking ring
tightly into position.
1 Connect the plug at the end of the speaker cable to the socket
on the handset and speaker connector, then secure the cable by
pushing it into the slot on the side of the connector.
1 Connect the plug at the end of the cable (Codan part number
08-01503-00x) to the socket at the end of the cable lead from
the RFU, then secure the locking ring tightly into position.
1 Connect the plug at the opposite end of the cable (Codan part
number 08-01503-00x) to the socket located at the base of the
antenna, then secure the locking ring tightly into position.
