INSTALLING THE TRANSCEIVER
OVERVIEW OF FIXED STATIONS
ENVOY™ TRANSCEIVER GETTING STARTED GUIDE 167
Connecting the transceiver supply
To connect the transceiver to the transceiver supply:
1 Connect the DC output from the transceiver supply to the plug at
the end of the 12 V cable lead from the RFU.
1 Connect the transceiver supply to the AC mains supply.
Earthing the transceiver
For information on earthing a fixed station, see the Installation section
in the Reference Manual.
Earthing the antenna
For information on earthing a fixed antenna, see the Installation section
in the Reference Manual.
